| Product Specifications: | |
| Product name | EPSON i3200-U1 |
| Ink Type | UV ink |
| Type | PrecisionCore MicroTFP print head |
| WidthxDepthxHeight | 69.1x 59.4 x 35.6 mm |
| Number of Nozzle | 3200 |
| Nozzle pitch/nozzle row | 1/300 inch |
| Nozzle rows | 8 rows |
| Nozzle Resolution | 300 npi /row 600 npi/2 rows |
| Max. number of colour inks | 4 colours |
| Droplet volumes | 6 pl (Single mode) |
| 6.3,1 2.3 pl (Multi mode) | |
* Four I3200-U1 Print Heads Speed (cmyk)
| Technical Specifications | |||
| Model | OR-1604E UV | ||
| Print Head | Double i1600-U1 Print Heads (i3200-UV Optional) | ||
| Printing Technology | Piezoelectric Inkjet | ||
| Acceptable Media | Width | 63.7 in.（1620mm） | |
| Thickness | Maximum 39 mil(1 mm) | ||
| Weight | 132 lb.（60kg） | ||
| Printing Width | 63in.（1600mm） | ||
| Ink Cartridges | Type | UV Ink | |
| Capacity | Bulk ink supply system with 500m ink tank | ||
| Color | CMYK/W+CMYK | ||
| Printing Resolution | Maximum 2400 dpi | ||
| Speed | CMYK | 6pass (720*900dpi) 21 ㎡/h | |
| W+CMYK | 6pass (720*900dpi) 11 ㎡/h | ||
| Curing Unit | Water-cooling UV lamp | ||
| Interface | Ethernet | ||
| Power Supply | AC 220V ± 10%, 50/60 HZ | ||
| Dimensions(with stand) | 102(W)x30(D)x62.2(H) in. ( 2590(W)x760(D)x1580(H) mm ) | ||
| Weight(with stand) | 240 kg | ||
| Package Dimensions | 124(W)x41(D)x59(H) in.( 3140(W)x1048(D)x1490(H) mm ) | ||
| Package Weight | 260 kg | ||
| Packing Dimensions | Power on | Temperature: 59℉ to 90℉ [15℃ to 32℃] (68℉[20℃] / Humidity: 35 to 80% (no condensation) | |
| Power off | Temperature: 41℉ to 104℉ [5℃ to 40℃] / Humidity: 20 to 80% (no condensation） | ||
| Weight | Data cable, media presser, user manual, maintenance tank, ink cartridges | ||
Leadshine DC Servo Motor
THK high precision mute rail
lgus mute drag chain, quite working environment guaranteed
Automatic up-and-down capping station, protects the print head more effectively
Equipped with two 11600 print heads, 3.5pl ultra-small ink droplets
1.6m UV roll to roll printer dedicated for white + color printing
Scientific head array, high-precision bottom plate, craftsmanship of quality
Light weight and compact design, saves workshop space
Feature of OR-1601TX
Latest technology of DTF , Want some quality clothing shirt? Try our DTF Print, same as silkscreen.
500mI large capacity ink supply system
High quality imported THK highprecision guide rail
Moisturizing cleaning assembly
Automatic take-up
LED backlight
Adjustable pinch rollers
